01. A masterpiece


Engine
The single overhead camshaft, liquid cooled, single cylinder engine features the latest in design and electronic technology. An outstanding maximum power output of 55 kW (74 hp) at 8,000 rpm and torque of 73,5 Nm at 6,500 rpm leave the rider in no doubt of the performance packed inside this lightweight unit.

Exhaust
The latest-generation 701 Supermoto is equipped with an improved exhaust system. Two lambda sensors, together with the catalytic converter - which has been relocated into the header pipe - control the emissions and ensure the machine is emissions compliant. This updated design allows riders to replace the silencer with one from the Technical Accessories range quickly and easily for enhanced performance.

Gearbox
The 6-speed gearbox is equipped with an optional Quickshifter+ that allows all gear changes to be made without using the clutch. The system uses two sensors, one of which is on the shift arm. When it detects movement on the gear lever, power is reduced for a fraction of a second. The second sensor is for gear selection, and once the next gear is engaged, full power returns. The Quickshifter+ delivers smoother acceleration, improved traction, and works even under heavy load.

Cylinder head
The compact, Single Overhead Camshaft (SOHC), 4-valve cylinder head features 42 mm intake valves and 34 mm exhaust valves. These are actuated by a reliable rocker arm system that delivers precise valve timing at high engine speeds. A dual-spark plug layout, with individually controlled ignition timing, ensures optimal fuel consumption.
